EES-CDV
4 EES-CDV Quick Reference Guide
1.3 System Specifications
System
Board ECM-CDV
CPU Onboard Intel® Atom™ D2550 1.86GHz CPU
BIOS AMI 16Mbit SPI BIOS
System Chipset Intel® NM10 Express Chipset
System Memory
One 204-pin DDR3 SODIMM Socket Supports Up to
4GB DDR3 800/ 1066 SDRAM
SSD One CompactFlash Type I/II Socket
HDD 1 x 2.5” SATA HDD/ SSD
Watchdog Timer Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step
H/W Status
Monitor
Monitoring System Temperature, Voltage with Auto
Throttling Control
External I/O
COM Port 1 x RS-232,1 x RS-232/ 422/ 485 (Setting by Jumper & BIOS)
LAN Port 2 x RJ-45
Antenna
2 Knockouts for Antenna Mounting
(Options to Add WiFi & 3G)
VGA 1 x VGA
HDMI 1 x HDMI
Audio Port Mic-in, Line-in, Line-out
USB Port 5 x USB 2.0
Expansions 1 x Mini-PCIe Socket
Display
Chipset Intel® Cedarview Integrated Graphics
Resolution CRT Mode: 1920 x 1200 @ 60Hz
Audio
Chipset Realtek ALC655 supports 5.1-CH Audio
Audio Interface Mic in, Line in, Line out
Ethernet
LAN Chip 2 x Intel® 82574L Gigabit Ethernet
Ethernet Interface 10/ 100/ 1000 Base-Tx Gigabit Ethernet Compatible
