SEAX-H81 User ’s Manual
SEAX-H81 User’s Manual 39
3.6.2.7.2 Serial Port 1 Configuration
Item Options Description
Serial Port
Enabled[Default],
Disabled
Enable or Disable Serial Port (COM).
Change Settings
Auto[Default]
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3,4,5,6,7,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,10,11,12;
Select an optimal setting for Super IO
device.
Device Mode
Standard Serial Port Mode[Default]
Full Duplex, ASKIR Mode
Half Duplex, ASKIR Mode
Change the Serial Port mode. Select
or
mode.
