Avalue EMX-B75 User Manual

Page 9

EMX-B75 User

’s Manual

EMX-B75 User

’s Manual 9

COM:

- COM2&COM10: RS-422/485

- COM4~9: support RS-232 connector, w/ +5V&+12V supported

GPIO: 8 bits

Audio:

1 x 2 x 5pin, pitch 2.54mm connector for front audio

USB:

USB2.0 - 2 x 2 x 5 pin, pitch 2.54mm connector

USB3.0 - 1 x 2 x 10in, pitch 2.0mm

1 x 2 x 5 pin, pitch 2.54mm JVGA

1 x 2 x 13 pin, pitch 2.54mm connector for printer

1 x 4 pin CPU fan connector with smart fan function supported

1 x 3 pin System fan connector.

1 x 3 pin, pitch 2.54mm SPDIF

1 x horizontal type battery connector

1 x 2 x 8 pin, pitch 2.54mm connector for front panel

1 x 2 x 2 pin ATX power connector for DC +12V input

1 x 20 pin ATX power connector

Display

Chipset

Intel B75 integrated

Resolution

3 display pipes supported

HDMI: 1080P

VGA: 1920x1200

DVI-D: 1920x1200

Audio

Chipset

Realtek ALC661 HD Audio Decoding Controller.

Audio Interface

Mic-In, Line-In

Ethernet

Chipset

1 x Realtek RTL8111E PCI-Express Gigabit Ethernet

Ethernet Interface

10/100/1000 GbE LAN

Mechanical &

Environmental

Power

Requirement

ATX

Power Type

ATX mode

ACPI

Single power ATX Support S0,S1, S3, S4, S5

ACPI 3.0 Compliant

Operating Temp.

0°C ~60°C
