EMX-B75 User

’s Manual

48 EMX-B75 User

’s Manual

3.6.2.8.7 Parallel Port Configuration

Item

Option

Description

Parallel Port

Enabled,

Disabled[Default]

Enable or Disable Parallel Port
(LPT/LPTE).

Change Settings

Auto[Default]

IO=378h; IRQ=7;

IO=378h; IRQ=6,7,10,11,12;
IO=278h; IRQ=6,7,10,11,12;

IO=3BCh; IRQ=6,7,10,11,12;

Select an optimal setting for
Super IO device.

Device Mode

STD Printer Mode[Default]

SPP Mode

EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode

ECP Mode

ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode

Change the Printer Port mode.
