2.4 Jumper and Connector List
Slots & socket
Label Function Note Page
FCPGA988 FCPGA988 socket 25
DIMMA1 204-pin DDR3 SO-DIMM Slot A1 28
DIMMB1 204-pin DDR3 SO-DIMM Slot B1 28
PCIEX16 PCI-e x16 Slot 34
MINI-PCIE MINI PCI-e Slot 34
CFAST Cfast Slot Rear Side 35
Jumpers
Label Function Note Page
JCMOS1 Clear CMOS 3 x 1 header, pitch
2.54mm
36
JPSON AT/ATX Mode Select 3 x 1 header, pitch 2.54mm 38
JLVDS_BKL1 BL Selec 3 x 1 header, pitch 2.54mm 37
JCOMPWR2
JCOMPWR3
COM2 COM3
RI/+5V/+12V Select
2 x 3 header, pitch 2.0 mm 37
Rear Panel Connector
Label Function Note Page
KBMS PS/2 Keyboard and Mouse 6-pin Mini-Din 23
COM1 COM1 Connector D-sub 9-pin, male 21
DVI (DVI/VGA
2 in 1 Conn)
DVI Port 29-pin DVI-D port 21
VGA1(DVI/VGA
2 in 1 Conn)
VGA Port D-sub 15-pin, female 21
HDMI1 HDMI Port HDMI 1.3 19-pin 21
LAN1USB12 RJ-45 Ethernet Connector x 1
USB 2.0 Connector x 2
21
LAN2USB34 RJ-45 Ethernet Connector x 1
USB 2.0 Connector x 2
21
Audio1 Audio Line-In , Line-Out , Mic.-In 5.1 Channel Audio I/O (3
jacks)
21
