Quick Installation Guide

ECM-CX700 Series Quick Installation Guide

13

2.3.12

TV Connector (JTV1)

Signal

PIN PIN

Signal

GND

2

1

CVBS/Pb

C/Pr 4 3 Y

GND

6

5

GND

DAC Output Mode

AV-signal

CVBS

S-video Y

C

HDTV

Pb

Y

Pr

2.3.13 Keyboard

&

Mouse Connector (KB2)

Signal

PIN PIN

Signal

NC

8

7

NC

MCLK 6

5

MDAT

+5V

4

3

GND

KCLK 2

1

KDAT
