ECM-LX800 Series

14 ECM-LX800 Series Quick Installation Guide

2.3.11

Serial port 3, 4 connector (JCOM3, JCOM4)

Signal

PIN

PIN

Signal

DCD

1

2

RxD

TxD 3

4 DTR

GND

5

6

DSR

RTS 7

8 CTS

RI

9

10

NC

2.3.12

General purpose I/O connector (JDIO)

Signal

PIN

PIN

Signal

GPO20

1

2

GPI10

GPO21

3

4

GPI11

GPO22

5

6

GPI12

GPO23

7

8

GPI13

GPO24

9

10

GPI14

GPO25

11

12

GPI15

GPO26

13

14

GPI16

GPO27

15

16

GPI17

SMB_CLK

17

18

SMB_DATA

GND 19 20 +5V
