ECM-A50M Quick Installation Guide

ECM-A50M Quick Installation Guide 21

2.3.18 Miscellaneous setting connector (JFP)

Signal

PIN

PIN

Signal

GND

10

9

CASEOPEN#

+3.3V

8

7

HD_LED#

PWR_LED#

6

5

3.3V

GND

4

3

SYS_RST#

GND

2

1

EXT_PWRBTN#

2.3.19 Keyboard & Mouse connector (JKBMS)

Signal

PIN

PIN

Signal

7

NC

MS_CLK#

6

5

MS_DAT#

+VCC_KB

4

3

GND

KB_CLK#

2

1

KB_DAT#
