ECM-PNV Quick Installation Guide

ECM-PNV Quick Installation Guide 17

2.3.14 Touch panel connector (JTOUCH)

PIN

4-WIRE

5-WIRE

8-WIRE

1

N/A

N/A

Right Sense

2 N/A N/A Left

Sense

3

N/A

N/A

Bottom Sense

4 N/A Sense

Top

Sense

5

Right

LR

Right Excite

6 Left LL Left

Excite

7

Bottom

UR

Bottom Excite

8 Top UL Top

Excite

9

GND

GND

GND

2.3.15 SPI connector (JSPI)

Signal

PIN PIN

Signal

VSPI

1

2

GND

SPICE# 3

4 SPISCK

SPISO

5

6

SPISI
