ECM-QM77
12 ECM-QM77 User ’s Manual
1.5 System Specifications
System
CPU
Intel® rPGA988B（Socket G2）supports Intel® Ivy Bridge Processors （35 ～ 45W
CPU）
BIOS
AMI uEFI BIOS, 64Mbit SPI Flash ROM
iAMT8.0 Supported
System Chipset Intel® QM77 Chipset
I/O Chip Nuvoton NCT6776F
System Memory
One 204-pin DDR3 SODIMM Socket Supports Up to
8GB DDR3 1333/ 1600 SDRAM
Watchdog Timer Reset: 1sec. ~ 255sec./min. and 1sec. or 1min./step
H/W Status
Monitor
Monitoring System Temperature, Voltage with
Auto Throttling Control
Expansion 1 x Mini PCIe
TPM TPM 1.2 supported
I/O
MIO 1 x RS-232, 1 x RS-232/ 422/ 485, LPC, 2 x SATA III
USB 2 x USB 2.0, 4 x USB 3.0
DIO 4-bit GPI, 4-bit GPO
Display
Chipset Intel® QM77
Resolution
VGA Mode: 1920 x 1200 @ 60Hz
HDMI Mode: 1920 x 1200 @ 60Hz
LVDS Mode: 1920 x 1200 @ 60Hz
Multiple
Display
VGA + LVDS + HDMI
LCD
Interface
Dual-channel 18/ 24-bit LVDS
Audio
HD Codec Realtek ALC892 Supports 7.1-CH Audio
Audio Interface Mic-in, Line-in, Line-out
Ethernet
LAN Chip
1 x Intel® 82574L Gigabit Ethernet
1 x Intel® 82579 Gigabit Ethernet
Ethernet Interface 10/ 100/ 1000 Base-Tx Gigabit Ethernet Compatible
Mechanical &
Environmental
