AVALON RF, INC.
Page 5
TA-8 Series User’s Guide & Operating Manual
2.
Specifications
2.1 Electrical Specifications.
Frequency Range:
2400 – 2483 MHz (standard)
2150 – 2500 MHz (extended – Option 4)
Tuning:
Individual tuning via front panel of 2 x DX604’s;
Tuning resolution:
250 KHz
RF Sensitivity:
typ better than - 84 dBm
Bandwidth:
27 MHz
Antennas:
7 x 15 dBic RHCP helical antennas to cover 360
o
azimuth
1 x 6 dBic RHCP patch antenna for over head
coverage
Video Output:
NTSC or PAL (depending on system ordered)
Video level:
1 Vp-p into 75 ohm, Negative Sync Tip, dc restored
to ground.
Telemetry Downlink (optional)
Telemetry output:
RS232 compatible signal levels with 8 data bits, No
Parity, 1 stop bit
Baud Rate:
4800 Baud
Control Uplink (optional)
Frequency Range:
392-420 MHz standard; any 40 MHz band in the
frequency range 350 MHz – 800 MHz possible
No of Channels:
16 through 4 DIP switches
RF Impedance:
50 ohm
RF Output:
1W
Antenna:
Half wave Omni directional (2.2 dBi gain); mounted
inside dome
Data Input:
RS232 compatible signal with 8 data bits, No Parity,
1 stop bit
Data Rate:
4800 Baud
