english 5 Uno Xtra
1. TECHNICAL DATA
As a stove of construction type 1, it is possible to connect it
to the chimney together with an exisiting other stove or
another hearth for solid fuels, as long as the chimney
dimensioning complies with DIN 4705, Part 3.
TECHNICAL DATA
Height 1220 mm
Width 588 mm
Depth 454 mm
Weight 278 kg
Weight with soap stone 338 kg
Flue pipe outlet diameter 150 mm
Nominal thermal output (EN 13240) 7 kW
Maximum thermal capacity 9 kW
Smallest heating capacity 3,5 kW
Room heating capacity (depending on
building insulation)
82 – 210
m³
Exhaust values for multiple use of the chimney in
accordance with DIN 4705, Part 3 and for the
calculation of the chimney measurements in
accordance with DIN 4705, Part 2
Fluegas mass flow
closed 6,5 g/s
Fluegas temperature closed 300 °C
Minimum feed pressure
Nominal thermal output
closed
12 Pa
at 0.8 times
n. ther. outp.
10 Pa
2. IMPORTANT INFORMATION
The installation and operation information given here is of
general nature. National and European standards, local and
building regulations as well as fire prevention laws must be
observed during the operation of the stove.
General safety instructions for the
operation of your stove
•
Thoroughly read the entire manual before starting up
your stove and observe the caution notices.
•
Your heating unit must not be moved without approved
means of transport with sufficient load-bearing capacity.
•
Your heating unit is not suitable to be used as a stand or
as a ladder.
•
Please keep in mind that your
stove’s surface heats up considerably
during operation. We therefore
recommend wearing a safety mitten
when operating your stove.
• Attention – stove varnish is no rust prevention!
•
Make your children aware of this particular danger and
keep them at a distance from the heating unit whenever it is
in operation.
•
Only burn approved fuels and materials listed in the
chapter “Clean Burning”.
•
The burning or placing of flammable or explosive
materials, like empty spray cans, etc. into the firebox as well
as the storage of such materials in the immediate vicinity of
your heating unit is strictly forbidden due the danger of
explosion.
•
Do not wear loose or flammable clothing when adding
fuel to the fire.
•
Placing non-heat-resistant objects on the heating unit
or in the vicinity of the heating unit is forbidden.
•
Do not lay laundry onto the stove for drying. Laundry
hung up to dry must be kept at a safe distance from the stove
because of the danger of fire.
•
The woodstove Uno Xtra is not suitable for long term
heating.
•
During the operation of your heating unit it is forbidden
to use flammable or explosive materials in the same or an
adjacent room to the one in which your heating unit is
located.
Setting up your stove
Required safety distances
(Minimum
distances – see name plate - in Fig. 2)
a > 800 mm
b > 130 mm
c > 150 mm
(a – toward the front in the radiated area)
(b – to the side)
(c – to the back)
Make sure that the room in which the stove is set up has at
least one door or window into the outside or is directly
adjacent to such a room. Other fireplaces and extractor
hoods must not be operated in the same room as the stove.
Floor load capacity
Make sure that the load capacity of the supporting
construction is sufficient to carry the weight of the entire unit,
before the heating unit is installed.
