UM-UV-621-8-Q215V1 www.austin-hughes.com
Physical
Specifi cation AP / NAP-8 OP-8
Product ( W x D x H ) 264.7 x 62.8 x 192 mm 261.7 x 56.8 x 189 mm
10.4 x 2.5 x 7.6 inch 10.3 x 2.2 x 7.4 inch
Packing ( W x D x H ) 515 x 117 x 429 mm 515 x 117 x 429 mm
20.3 x 4.6 x 16.9 inch 20.3 x 4.6 x 16.9 inch
Net Weight 2.4 kgs / 5.3 lbs 1.5 kgs / 3.3 lbs
Gross Weight 4.3 kgs / 9.5 lbs 3.4 kgs / 7.5 lbs
Applicable
Format VGA Input PC Signal 800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
8.4” LCD Display
P.11
