2 > structure diagram - op-8, Op-8, Front view – Austin Hughes OP-8 User Manual
Page 11: Rear view, 4" lcd display
UM-UV-621-8-Q215V1 www.austin-hughes.com
Rear case
LCD panel
Audio speaker ( for Audio or TV option )
Universal open frame mounting
LCD membrane
Extended remote sensor membrane cable
( 66cm from AD board to sensor end )
6
6
1
2
3
4
5
< 2.2 > Structure Diagram - OP-8
Front view
1
2
Rear view
5
OP-8
4
3
8.4" LCD Display
P.7
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
OP-8
261.7 x 56.8 x 189 mm
10.3 x 2.2 x 7.4 inch
515 x 117 x 429 mm
13.5 x 2.5 x 10 inch
1.5 kg
3.3 lbs
3.4 kg
7.5 lbs
