55" FHD LCD Display
Front view
1
2
3
Rear view
6
Rear case
LCD panel
8mm aluminum front bazel
Audio speaker, pair
LCD membrane
Wall-mount bracket
Remote sensor
1
2
3
4
5
5
6
4
< 1.2 > Structure Diagram - AP / NAP-W55
AP-W55
NAP-W55
P.2
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
AP-W55
1325 x 75.3 x 796 mm
52.2 x 3 x 31.3 inch
1455 x 917 x 212 mm
57.3 x 36.1 x 8.3 inch
45.2 kg
99.4 lbs
54.3 kg
119.5 lbs
NAP-W55
1325 x 75.3 x 796 mm
52.2 x 3 x 31.3 inch
1455 x 917 x 212 mm
57.3 x 36.1 x 8.3 inch
50.2 kg
110.4 lbs
59.3 kg
130.5 lbs
