Rear case
LCD panel
6mm aluminum front bazel
Audio speaker, pair
LCD membrane
Remote sensor
1
2
3
4
5
6
1
2
3 Front view
Rear view
5
< 1.2 > Structure Diagram - AP / NAP-X17
AP-X17
NAP-X17
P.2
4
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
468.5 x 57.1 x 331 mm
18.4 x 2.2 x 13 inch
615 x 113 x 523 mm
24.2 x 4.4 x 20.6 inch
4.9 kg
10.8 lbs
7.7 kg
16.9 lbs
AP-X17
NAP-X17
6
