LCD interchangeable module kit
Installation Slides
Carry handle to release the 2-pt lock
LCD membrane
1
2
3
5
7
6
7
6
Membrane switch (KVM option)
Keyboard interchangeable module kit
Mouse interchangeable module kit
4
RKP2417 or RKP2419 unit X 1
- CE-6 6ft Combo KVM cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
The above package content is only for the single console models.
It varies with options such as KVM, HDMI, DVI-D, AV, audio & DC power.
< 1.1 > Package Content
P.1
< Part 1 >
< 1.2 > Structure Diagram
3
5
4
