Austin Hughes L120 - Manual (Page 6)

UM-CV-751-L120-Q215V1 www.austin-hughes.com
1
3
Carry handle to release the 2-pt lock
LCD interchangeable module kit
Installation Slides
LCD membrane
1
2
3
5
6
7
7
Membrane switch (KVM option)
Keyboard interchangeable module kit
Mouse interchangeable module kit
4
4
6
5
L120 unit X 1
- CE-6 6ft Combo KVM cable X 1
- Power cord X 1
- M6 screw, cage nut & cup washer X 8
The above package content is only for the single console models.
It varies with options such as KVM, HDMI, DVI-D, AV, audio & DC power.
< 1.1 > Package Content
P.1
< Part 1 >
< 1.2 > Structure Diagram
2
