KVM unit
•
M-IP813 or U-IP1613 or
M-IP824 or M-IP1624 KVM unit x 1
•
Mounting set w/ bracket & screws x 1
•
Power adapter w/ power cord ( for KVM ) x 1
•
Receiver box for remote console x 1
•
Power adapter w/ power cord ( for receiver ) x 1
•
CE-6 6ft Combo KVM cable for receiver box x 1
< 1.1 > Package Contents
Matrix DB-15 IP KVM
< Part 1 > Matrix DB-15 KVM
P.1
M-IP813
Local Console
M-IP1613
1
M-IP824
M-IP813 / M-IP1613
M-IP824 / M-IP1624
M-IP1624
Power
Remote Console 1
out
in
Cascade
Local Console
1
Remote Console 1
out
in
Cascade
2
Power
