434
N104-030
100000003285
Paper feed shaft
2
435
N104-029
130464
100000003284
Platen
1
436
N104-047
100000003287
Cam shaft B
1
437
N104-130
100000003336
Cartridge holder R
1
438
N104-03
100000003275
Paper guide plate
1
439
N104-131
100000003337
Cartridge holder L
1
440
N104-002-A
100000003273
Baseplate L assembly
1
441
N104-145-A
130109
200000021009
Pulley Carriage Return
1
442
φ3*φ7*0.6
100000001865
E ring
4
443
N104-147
100000003346
Pulley shaft
1
444
N104-148-A
100000003314
Pulley frame foundation
assembly
1
445
N104-151
130440
100000003316
Pulley spring
1
446
N104-152
100000003315
Spring support plate
1
447
FP8800-FSM149-A
100000050190
Pulley frame foundation
1
448
PM3*5
100000000173
Screw
1
449
N104-163B
130453
100000003279
Paper guide plate padding
2
450
N104-004
100000003280
Paper guide plate B
1
451
N104-080
200000025489
ROM cover
1
452
N104-272
100000003358
Ground spring B
1
453
N104-271
100000003356
Ground plate
1
454
N104-005
100000003281
Paper guide plate C
1
455
N104-054
200000025435
Pinch roller
14
456
N104-053
200000025453
Pinch roller transmitting gear
14
457
N104-055
200000025433
Pinch roller holder
7
458
φ7*φ14*0.8
100000001519
Retaining ring
28
459
N104-069
100000004144
Friction spring 2
7
460
N104-056
200000025434
Pinch roller holder B
7
461
N104-078
100000003290
Friction spring B
7
462
N104-049
100000003289
FC shaft B
1
463
N104-044
100000004138
Pinch roller drive shaft
1
464
N104-045
100000004142
Pinch roller drive shaft B
1
465
N104-048
100000003288
FC shaft
1
466
N104-090
200000025477
Paper cutter cover
1
467
N104-281
100000004124
Sound-absorbing sponge
1
468
N104-222
200000025496
C cover
1
469
N104-221
200000025457
Change lever
1
470
N104-232A
130412
200000000252
Sensor harness A assembly
1
471
N104-223
100000004137
Spring A
1
472
N104-220
200000025497
C baseplate
1
473
N104-096A
130114
200000000252
Paper sensor assembly
1
474
N104-094
200000025502
Paper sensor cover
1
475
N104-282
100000004125
Sound-absorbing sponge D
1
476
N104-091
100000004123
Paper cutter
1
477
N104-189
200000025474
Flap
3
478
N104-188
200000025475
Flap B
1
479
N104-181
200000025476
Flap C
1
480
N104-166
100000003282
Flap spring
2
481
N104-187
100000004129
Flap shaft
1
482
N104-001-A
100000003259
Baseplate R assembly
1
