pg. 9
Parts list
I.D. Number
Range
Assembly Name Specification Number
150-199 Whole Printer Accel7450-EXP000
200-219 Upper Housing Assembly Accel7450-EXP010
220-239 Bottom Housing Assembly Accel7450-EXP020
240-289 Tractor Assembly Accel7450-EXP030
290-309 Front Table Assembly Accel7450-EXP040
310-509 Mechanism Assembly Accel7450-EXP050
510-529 Control Panel Assembly Accel7450-EXP051
530-549 Adjusting Panel Assembly Accel7450-EXP052
550-599 Carriage Assembly Accel7450-EXP053
I.D.
No.
Specification No. Part Number Catalog No. Name
Assy
QTY
Accel7450-EXP000 Whole Printer
151 φ5 100000004182 Toothed lock washer 2
152 KM3*8 100000000629 Flat head screw 2
153 N104-241 100000004178 Inlet harness A 1
154 PW3M4*6*#8 100000003334 Pan head screw 2
155 N104-242 100000004179 AC harness A 1
156 N104-227 200000025480 Mechanism holder B 2
157 N104-228 200000025481 Mechanism stopper 2
158 PW3M4*28*#8 100000003256 Pan head screw 2
159 TM4*8 100000003251 Truss head screw 4
160 PW3M4*10*#8 100000001917 Pan head screw 3
161 RM4*30 100000003254 Mechanism lock screw 3
162 N104-226 100000003255 Mechanism holder 2
163 PW3M4*35*#8 100000003253 Pan head screw 1
164 CRO-22B-11-1 130432 100000010666 Power switch 1
165 N104-243 130420 200000025438 Switch holder 1
I.D.
No.
Specification No. Part Number Catalog No. Name
Assy
QTY
200 ACCEL7450-EXP010 130099 200000029697 Upper housing assembly
201 220*50 510000000504 Ribbon exchange label 1
202 N104-255 510000000414 Tractor caution label 1
203 FP8800-PAK011 510000011309 Nameplate label 1
204 N104-216 200000025498 Cover stop board 1
205 HPB3*8-C 100000000627 Pan head tapping screw 2
206 N104-292 100000004188 Printer cover shaft washer 1
207 N104-215 100000004187
Rotating shaft of printer
cover
2
208 N104-280 100000004189 Sound-absorbing sponge B 2
209 N104-212A 130405 200000029091 Printer cover assembly 1
210 N104-210 200000025467 Upper housing 1
