-38- Clarke ® American Sanders Operator's Manual (EN) - Floorcrafter
LAMP ASSEMBLY
Item Ref. No. Qty Description
10252A 1 Lamp Assy
1 962974 2 Screw 6-32x1/2 Fh Ph
3 39862A 1 Enclosure Lamp
4 39863A 1 Cover Lamp
5 40528A 1 C14 Inlet Asm
6 40783A 2 Tap Splice 22-16 Awg
7 51612A 2 Bumper Reccessed Nap Sac
8 52350B 1 Ballast 120-277v 13w
9 52356A 2 Adaptor Lamp
10 52357A 2 Lamp 13w Fluorescent
11 52358A 2 Socket Assy
12 52367A 2 Grommet
13 920056 2 Nut, 6-32 E.S.N.A. Nylock
14 920065 9 Nut, 8-32 E.S.N.A
15 962027 8 Screw, 8-32 X 1/2 P.H.
16 60550A 1 Reflector Lamp
17 60551A 1 Bracket, Lamp
18 85303A 5 Screw 8-32 X.375
1
3
4
5
6
7
8
10
11
12
13
14
15
16
17
18
9
