Clarke ® American Sanders Operator's Manual (CE) - American B-2 - 5 -
INTRODUCTION AND MACHINE SPECIFICATIONS
The B-2 is specifically designed for finishing floor edges, stairs, and other hard-to-reach surfaces. The handle location and low center of gravity
make the B-2 easy to operate.
The excellent cutting power comes from a powerful universal type motor. A motor that delivers maximum performance without slowing down or
overheating. Its exclusive two speed control when switched to hi-speed produces 3200 rpm for fast, rough sanding. At low speed, the B-2 operates
at 2800 rpm for fine, finish sanding. A non-marking disc guard protects the rubber pad, permitting the edger to work right up to the baseboard or wall.
1-Powerful Universal Motor
2-Comfortable Operating Handles
3-Aluminum Alloy Casting
4-Balanced Sanding Disc for perfectly matched job
5-Non-Marking Roller Guard
6-Non-Marking Swivel Type Casters
7-High Low Switch
*-Hardened Steel Alloy Pinon and Drive Gear
*-Powerful Vacuum Fan for efficient dust pickup
SPECIFICATIONS
Model 07097A
Voltage / Frequency 220V-240V / 50-60Hz
Amperage 6.5
Motor 1450W (1HP)
Sound Level 91dB (A)
Vibration 14.3 m/s 2 rms
Abrasive Size 178mm x 22 mm Dia. (7” x 7/8” Dia.)
Disc Rate High 3200 RPM
Disc Rate Low 2800 RPM
Gears Hardened steel alloy pinion and drive gear.
Bearings Sealed ball bearings, lifetime lubricated.
Dust Collector Powerful vacuum fan, full aluminum skirt
Power Cord 12m H07RN F3G 1.5mm 2
Dimensions 356 x 260 x 343mm (14 x 10½ x 13½)
Weight 14.5 kg (32 lbs.)
Shipping Weight 21 kg. (46 lbs.)
1
2
3
4
5
6
7
