Tuning tips – Alwarerc Senrigan GP-55 3-Axis Brushless Gimbal V2 With Bluetooth (For 600 -1000 Size Multicopter) User Manual
Page 16
5. Tuning Tips
Specification for the 32 Bits Alexmos Controller with GP-55V2 Gimbal
32 bits SimpleBGC Camera Stabilizer System with Alu Case protection
Twins IMUs with Alu Case protection
Firmware: The newest 2.42b6 (updateable freely in the future)
Power supply voltage: 8–25 V (2s-6s LiPo), Default setting for 7.4v Lipo
Maximum motor current: 1,5 A/ each motor
Voltage Output: 5V 1A (suitable to power the receiver directly)
Pre-programmed for Sony NEX N7/ similar size Mini DSLR Cameras.
Alexmos website download 2.42b6
User manual: SimpleBGC_32bit_manual_2_42_eng
Remarks: GP-55 V2 Gimbal Controller is pre-programmed for stable performance with Sony NEX N7 or
similar size Cameras. So no tuning is needed normally. If you want start tuning yourselves, please follow the
Official Manual from
Default Setting of GP-55 V2:
16
