Specifications

cPCI-3970

2.2

cPCI-R3P00(T) RTM Specifications

1. cPCI-R3P00T GbE ports are LAN1/2 due to PCI-Express root port

sequence requirements of the PCH; cPCI-3970 front panel GbE
ports change to LAN3/4 when using the cPCI-R3P00T.

2. A DB-9-to-DB-9 dongle to convert the cPCI-R3P00 RS-422/485

pin definitions to common pin definitions is included in the package
(“COM5 Connector (DB-9)” on page 46).

Mechanical

Board Size
• cPCI-R3P00: 100mm x 50mm
• cPCI-R3P00T: 100mm x 80mm
Dual-slot (8HP, 40.64mm)
(optional single slot upon request )

Gigabit
Ethernet

• cPCI-R3P00: Two GbE ports switched from front panel by

BIOS setting (LAN1/2)

• cPCI-R3P00T: Two GbE ports from independent Intel

82580DB GbE controller

Serial Ports

• Two serial ports on I/O panel from pin header
• COM5 converted from USB supporting RS-232/422/485

• COM4 provides RS-232 Tx, Rx signals only

Storage
Interface

• Three 7-pin Serial ATA ports

Faceplate I/O

• 2x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports
• Analog DB-15 VGA port
• 2x COM ports

Table 2-2: cPCI-R3P00(T) RTM Specifications

NOTE:

Specifications are subject to change without prior notice.
