Specifications

9

cPCI-3615

2.2

I/O Connectivity Table

1. Software switchable from front port(s).

Function

cPCI-3615

(4HP)

cPCI-3615D

(8HP)

cPCI-3615P

(12HP)

cPCI-R3610(T)

Front I/O Onboard Front I/O Onboard Front I/O Onboard Front I/O Onboard

Gigabit
Ethernet

Y x2

–

Y x2

–

Y x2

–

Y x2

(1)

–

COM

–

Y

–

Y

–

Y x2

–

USB 2.0

Y x2

–

Y x4

–

Y x4

–

Y

–

VGA

Y

–

Y

–

Y

–

Y

(1)

–

Serial
ATA

–

–

–

Y

(2.5” HD)

–

Y

(2.5” HD)

–

Y x2

(7-pin)

CF

–

Y

–

Y

–

Y

–

–

PS/2
KB/MS

–

–

Y

–

Y

–

–

–

Line-in

–

–

Y

–

Y

–

–

–

Line-out

–

–

Y

–

Y

–

–

–

PMC/
XMC

–

–

–

–

–

Y

–

–

GP LED

Y x2

–

Y x2

–

Y x2

–

–

–

Reset
Btn.

Y

–

Y

–

Y

–

–

–
