12
• Introduction
♦
System IO mapping:
§ Assigned by PCI BIOS
§ Shared IRQ
♦
Flow control
§ Xon/Xoff control
§ RTS/CTS control
♦
Port Capability:
•
8 independent RS-232C compatible ports
•
Optional external C588XB box for extending to 8 isolated
RS-232/422/485 port
•
Max. port per system: 16 (2 cards)
♦
Baud rate: Each port can be configured to 50~115,200 bps
♦
Operation System Compatibility: Windows 95/98/NT
♦
Connector: DB62 female connector
♦
Cable: External cable with 8 standard DB25 male connector
♦
Operating temperature: 0 ~ 55
°C
♦
Storage temperature: -10 ~ 70
°C
♦
Humidity: 10% ~ 95%, non-condensing
♦
Power consumption: +5V @ 1400mA typical
