Introduction 5
PM-7841 Specification Table
Size 132(L)mm x 98(H)mm
Ports 2 CAN channels (V2.0 A,B)
CAN Controller SJA1000
CAN Transceiver 82c250/82c251
Signal Support CAN_H, CAN_L
Isolation Voltage 1000 Vrms
Connectors Dual 5 male connectors
Operation Temperature 0 ~ 60
°
C
Storage Temperature -20
°
C ~ 80
°
C
Humidity 5% ~ 95% non-condensing
IRQ Level Set by Jumper
I/O port address Set by DIP Switch
Memory Mapped Space 128 Bytes by Software
Power Consumption
(without external devices)
400mA @5VDC ( Typical)
900mA @5VDC ( Maximum)
Size 90.17(L)mm x 95.89(H)mm
Table 1-3: PM-7841 Specifications
Table 1-2: cPCI-7841 Specifications
