PARTS LIST
MODELS (V)T32N, (V)T32NB, (V)T32NR, (V)T32NRB, (V)T32P, (V)T32PB,
(V)T32PR, (V)32PRB AND CHDV32NR
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 36 of this manual.
KEY
NO.
PART NO.
DESCRIpTION
QTY.
1
**
Firebox Assembly
1
**
Face Weldment
1
3
10889-01 Door Assembly, T & CHDV Models Only
1
10889-0 Door Assembly, VT Models Only
1
4
109155-01 Top Stamped Panel Assy, T3N/P, T3NB/PB Models
1
108903-01 Top Rolled Louver Assy, T3NR/PR, T3NRB/PRB & CHDV3NR
Models
1
5
109155-0 Bottom Stamped Panel Assy, T3N/P, T3NB/PB Models
1
108903-0 Bottom Rolled Louver Assy, T3NR/PR, T3NRB/PRB,
CHDV3NR Models
1
6
108895-01 Fireplace Top
1
7
**
Fireplace Top Insulation
1
8
**
Fireplace Surround
1
9
108885-01 Burner Assembly (Natural)
1
108885-0 Burner Assembly (Propane/LP)
1
9-1
1110
Screw #8-3 x 3/8 PPH Zinc
9-
11105
Screw #10 x 1/ Zinc
9
9-3
11179
Screw #10-4 x 1/4 Zinc
4
9-4
1137
Screw, Trilab M4 x 8mm
1
9-5
14389
Millivolt Valve (Natural)
1
14390
Millivolt Valve (Propane/LP)
1
9-6
1449
Piezo Ignitor
1
9-7
14500
Brass Fitting
9-8
1453
Flexible Connector
1
9-9
14511
Ignitor Bracket
1
9-10 1458
Brass Elbow Fitting
1
9-11 104506-5 Orifice (Natural)
1
14514
Orifice (Propane/LP)
1
9-1 104509-0 Aluminum Tubing Assy
1
10
108890-01 Burner Base Gasket
1
11
108897-01 Rear Refractory Brick Panel (B Models Only)
1
1
10908-03 Heat Shield
1
13
108901-01 Right Refractory Brick Panel (B Models Only)
1
14
108901-0 Left Refractory Brick Panel (B Models Only)
1
15
11418
Push-On Nut
16
108440-01 Screen
17
109479-01 Screen Rod
1
18
1413
Strain Relief
1
19
1171
Gas Knock-Out Cover
0
4353
Handy Box Assembly
1
1
4460
Gas Conduit Assembly
1
109-01 Log Set
1
-1 109403-01 Front Log (Log 1)
1
- 109404-01 Rear Log (Log )
1
-3 109407-01 Base Log (Log 3)
1
-4 109406-01 Crossover Log (Log 4)
1
-5 109405-01 Left Top Log (Log 5)
1
-6 109408-01 Right Top Log (Log 6)
1
PARTS AVAILABLE - NOT SHOWN
5487
Lava Rock/Bag Assy
1
PCDM-3T Conversion Kit (CHDV3NR only)
1
** Not a field replaceable part.
