16

Installation

cPCI-7252 Pin Assignment

Signal Pin Pin Signal

IGND

1

26

IGND

DI8

2

27

DI12

DI9

3

28

DI13

DI10

4

29

DI14

DI11

5

30

DI15

DI0L

6

31

DI4H

DI0H

7

32

DI4L

DI1L

8

33

DI5H

DI1H

9

34

DI5L

D2IL

10 35

DI6H

DI2H

11

36

DI6L

DI3L

12 37

DI7H

DI3H

13 38

DI7L

NO0

14 39

NO5

NO1

15 40

NO4

COM0 16 41 COM5
COM1 17 42 COM4

NC0

18 43

NC5

NC1

19 44

NC4

NO2

20 45

NO7

NO3

21 46

NO6

COM2 22 47 COM7
COM3 23 48 COM6

NC2

24 49

NC7

NC3

25 50

NC6

Table 2-4: CN1 - cPCI-7252 Pin Assignment
