Hardware Information 11
PCIe/PXIe-8638
3 Hardware Information
3.1 Functional Block Diagram
Figure 3-1: PCIe to PXIe Extension Kit Functional Block Diagram
3.2 PCIe-8638 Layout, Connectors and Jumpers
Figure 3-2: PCIe-8638 Mechanical Layout
Table 3-1: PCIe-8638 Mechanical Layout Legend
A PCIe x8 external cabling
B PCIe x8 edge finger
C SW1
A
B
C
ON DIP
1 2 3 4
