Acrosser AR-R5700 - Manual (Page 3)

3
1. Introduction of AR-R5700 Series
AR-R5700 series is a 1U height, rack-mounted system product. It is designed mainly for
networking applications. With powerful Intel CPU core & an expansion module in option for
optical/copper-wire LAN interface, AR-R5700 can satisfy the user requirements in performance
and complex networking configurations. Besides, excellent operating temperature at least 45℃
reliability, it can be installed in more severe environment than a generally commercial network
device.
AR-R5700 has diverse physical interface in the front panel (fiber interface in option), such as up to
10 Giga LAN ports, two fiber LAN ports in option, build-in LEDs, 2 USB Ports, one Console port,
Power Button, Reset Button, and Keyboard/Mouse interface. In addition, the system can be
extended SSD/memory capacity via adding-in DRAM module and CF card according to the users
needs.
1.1 Discrimination (included Rubber Foot)
Description AR-R5500
CPU Board AR-B5700series
Dimensions 440Ч44Ч448 (mm)
