Acrosser AR-B104B - Manual (Page 6)

AR-B104B User Manual
6
1.1 Specifications
Module Name: AR-B104B/4P or 8P.
Dimension: 90.2mm x 95.9mm.
Controller: Oxford OXuPCI954.
RS232: Isolation 2KV and ESD contact 8KV air 15KV protect.
Function selectable: RS232/RS485/RS422 selectable by jumper
System Interface: PCI Local bus specification V3.0 in PCI-104 format
Connector: 2 x 22 2.0mm pin head 180 degree.
Operation Temperature: AR-B104B/4P: -20 ℃ to 85 ℃； AR-B104B/8P: -20 ℃ to
70 ℃ .
Support: OS Windows XP/XPE, Linux FC6/FC7.
