Mainboard illustration (Bottom Side)

BH1

System RTC battery socket

In

tel Atom Pineview D425/D525 CPU

PCIE_R1

PCI-E & PCI riser card socket

Intel ICH8M

CN_DIMM2

204-Pin DDR3 Socket

CN_DIMM1

204-Pin DDR3 Socket
