part a. getting comfortable.
Learning about the interface & controls.
A.1
MAIN SWITCHES AND INTERFACE
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
External DC Supply Jack (6V DC to 9V DC)
Telephone Configuration Switch
Line-In Jack (ø3.5mm stereo) from Computer Line Out
Line-Out Jack (ø3.5mm stereo) from Computer Line In
Power On/Off Switch
Rotary Mic Volume Control
Mute Switch
Telephone/Computer Application Switch
Computer Headset Jack (ø3.5mm stereo) from Speaker Plug
Computer Headset Jack (ø3.5mm stereo) from Microphone Plug
Headset/Handset Application Switch
Modular Jack for Telephone Headset
Slide Reception Volume Control
Modular Jack for Telephone Handset
Modular Jack for Input from Telephone Unit
Battery Compartment Door
