Specifications
■ Power Amp Section
Rated output, both channels driven 80 W + 80 W (8 ohms, 20 - 20 kHz, 0.07%THD)
160 W + 160 W (4 ohms, DIN 1 kHz, 0.7%THD)
Total Harmonic Distortion 0.01% (-3 dB rated output, 8 ohms load)
■ Preamplifier Section
Input sensitivity/Impedance
PHONO 2.5 mV/47 kohms (MM), 200 µV/100 ohms (MC)
CD, TUNER, DVD/AUX 150 mV/47 kohms (Source Direct OFF)
TAPE-1/DAT, TAPE-2/MD 150 mV/47 kohms (Source Direct OFF), 150 mV/13 kohms (Source Direct ON)
RIAA deviation/PHONO 20 Hz ~ 20 kHz ±0.3 dB (MM/MC)
■ General Characteristics
S/N ratio (A-weighted)
PHONO 91 dB (MM), 76 dB (MC)
CD, TUNER, DVD/AUX 110 dB (input terminals shorted/Source Direct ON)
Tone controls 100 Hz ±8 dB (BASS), 10 kHz ±8 dB (TREBLE)
■ Other Specifications
Power supply AC 120 V, 60 Hz
Power consumption 6 A
Dimensions 434 (W) x 180 (H) x 478 (D) mm (including feet, knobs, terminals)
17-1/8” x 7-1/8” x 18-3/4”
Weight 20.0 kg, 44 lbs
*Design and specifications are subject to change without notice.
DENON ELECTRONICS LABRADOR S.A. DE C.V.
DIVISION OF DENON CORPORATION (USA) ZAMORA NO.154, COL. CONDESA, MEXICO D.F.C.P. 06140
222 NEW ROAD, PARSIPPANY, NEW JERSEY 07054, USA TEL: 286-55-09/79
TEL: 973-396-0810 www.del.denon.com
DENON CANADA INC. NIPPON COLUMBIA CO., LTD.
17 DENISON STREET, MARKHAM ONTARIO, CANADA L3R 1B5 14-14,AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-11, JAPAN
TEL: 905-475-4085 Denon Home Page Address: http://www.denon.co.jp
■ Rectifier Circuit Accommodating High-Speed,
Large-Capacity Current
Advanced technology that was developed for the DENON
PMA-S1 integrated amp has been used in the rectifier circuit
of the PMA-2000R. A large rectifier bridge with superior abili-
ty to supply high current and a first recovery diode with dra-
matically accelerated operating speed have been connected
in parallel so that the PMA-2000R can accommodate both
high speed and high current, to ensure true low impedance
drive capability.
■ Highly Rigid, 6-Block Separated Chassis
The highly rigid chassis of the PMA-2000R is based on the
twin monaural construction featuring independent power amp
blocks for the left and right channels in order to eliminate
degradation in sound quality caused by noise and mutual
interference between the circuits. In addition, circuits han-
dling signals of different levels are also isolated in their own
separate blocks, resulting in a sophisticated 6-block design
that preserves signal purity all the way from input to output.
■ Large, Gold-Plated Speaker Terminals
Supporting Bi-Wiring
■ High-Performance MM & MC Phono Stage
■ Premium Parts Selected for Best Sound Quality
High current, high voltage, low ESR storage capacitors
