Product Overview - continued
1) Power Indicator -
2) Downstream Ports -
3) Port Status Indicators -
4) Root (Upstream) Port
5) AC Adapter Power Connection
Blue LED when lit indicates
when USB Hub is receiving power.
Connect your USB devices to
these ports. (Includes 1 Flash Drive port)
Green LEDs indicate port
status and overcurrent detection. When a device is
connected to one of the ports, the associated LED
will illuminate. If an overcurrent condition occurs,
the LED for that port will turn off, indicating a
problem with that device.
Connect your computer to this port to provide a link
between the hub and devices.
Connect your AC power adapter here. This hub
operates in self-powered mode to ensure sufficient
power is provided to connected USB devices.
