PARTS LIST
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 29 of this manual.
PART NUMBER
KEY EFS33NR
EFS33NRA
EFS33PR
EFS33PRA
NO. VSGF33NR
VSGF33NRA VSGF33PR
VSGF33PRA DESCRIPTION
QTY.
1a ____
110881-04 ____
110881-04 Front Log
1
1b ____
110881-05 ____
110881-05 Middle Log
1
1c
____
110881-06 ____
110881-06 Rear Log
1
2a 104388-02 ____
104388-02 ____
Front Log
1
2b 104390-02 ____
104390-02 ____
Middle Log
1
2c
104392-02 ____
104392-02 ____
Rear Log
1
2d 104394-02 ____
104394-02 ____
Crossover Log
1
3
099387-12 099387-12 099387-09 099387-09 Pilot Tube
1
4
M11084-26 M11084-26 M11084-26 M11084-26 Hex Screw, #10
2
5
098304-01 098304-01 098304-01 098304-01 Screw, #10 Phillips, Black
8
6
103779-01 103779-01 103778-01 103778-01 ODS Pilot (Propane/LP)
1
7
098249-01 098249-01 098249-01 098249-01 Nut
4
8
101006-02 101006-02 101006-02 101006-02 Pilot Bracket
1
9
101330-05 101330-05 101330-05 101330-05 Front Burner Assembly
1
10 109824-02 109824-02 109824-02 109824-02 Rear Burner Assembly
1
11
**
**
**
**
Base Assembly
1
12 098271-10 098271-10 098271-10 098271-10 Ignitor Cable
1
13 **
**
**
**
Firebox Bottom
1
14 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor
1
15 101004-08 101004-08 101004-01 101004-01 Front Burner Injector
1
16 104241-02 104241-02 104241-02 104241-02 Switch Bracket
1
17 103782-01 103782-01 103782-01 103782-01 Valve Bracket
1
18 103284-03 103284-03 103284-03 103284-03 Wiring Harness
1
19 102846-02 102846-02 102846-02 102846-02 Burner Tube
1
20 097809-02 097809-02 097809-02 097809-02 Adapter
1
21 M12461-26 M12461-26 M12461-26 M12461-26 10/32, Screw
4
22 098265-02 098265-02 098265-02 098265-02 Elbow, Male
1
23 103781-01 103781-01 103781-02 103781-02 Gas Valve Assembly
1
24 099998-01 099998-01 099998-01 099998-01 Switch
1
25 101004-14 101004-14 101004-15 101004-15 Rear Burner Injector
1
26 101628-03 101628-03 101628-03 101628-03 Flex Hose
1
27 M11084-38 M11084-38 M11084-38 M11084-38 Screw
2
28 901056-01 901056-01 901056-01 901056-01 3/8" Flare x 1/2" NPT
1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate
1
103877-01 103877-01 103877-01 103877-01 Lighting Instructions Plate
1
**Not a field replaceable part.
