Specification – Hyundai H-CDM8045 User Manual
Page 29
29
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General.
Power supply:
14.4V DC
Current consumption/Fuse:
max. 15A/ 15 A
Maximum power output:
50Wx4 channels
Dimensions (W x H x D)
178 x 50 x 192 mm
Working temperature range:
-10º - +60º
FM Stereo Radio.
Frequency range:
65.0 74.0/87.5 - 108.0 MHz
Usable sensitivity/ I.F. Frequency:
15 dB uV/ 10.7 MHz
MW Section.
Frequency range:
522 kHz-1620 kHz
Audio Specification
Maximum Output
2Vrms(+/-3dB)
Frequency Response
5Hz to 20KHz
S/N Ratio(A-vtd)/ Separation
65dB/ 60dB
Line out.
Output:
CD max 2000 mV
