The example on the following page will better demonstrate how to use Text
Messaging. In this example station 205 is making an off hook voice announce-
ment to station 205 who after hearing the announcement will respond with a text
message.
STATION 201: LINDA STATION 205: JOHN
received a call on line 702 is talking on line 701
Talking on line 702
702: 01:15 701: 05:25
CONF PAGE MUTE
Press TRANSFER
Transfer:
RETURN
Dial 205
205:busy
OHVA CAMP ON
OHVA to 205 OHVA from 201
TMSG REJECT
Wait for reply GIVE THE CALL
TMSG:01 SEND
Dial 03 or press Ï twice
ASK THEM TO HOLD
TMSG:03 SEND
ASK THEM TO HOLD Wait for reply
TMSG EXIT
702: 01:45 701: 05:55
CONF PAGE MUTE CONF PAGE MUTE
Р
Р
Р
50
ADD-ON MODULE
32 BUTTON MODULE WITH KEYSET
The 32 button module is used when you need more programmable keys added
to your keyset. The 32 tri-colored LED’s provide better visual indication of call
status and call progress. The extra programmable keys are used exactly like
the one on your keyset. Make them DSS/BLF keys or any combination of fea-
ture keys. The 32 button does not support executive off-hook voice announce
(OHVA) and does not have a microphone. A maximum of four 32 button mod-
ules can be assigned to any keyset.
64 BUTTON MODULE WITH KEYSET
The 64 button module is used when you need more programmable keys added
to your keyset. The 64 red LED’s provide visual indication of calls and features.
The extra programmable keys are used exactly like the ones on your keyset.
Make them DSS/BLF keys or feature keys. As a DSS/BLF the size of the 64
button module allows for greater call status and faster call processing. The 64
button module does not support executive off-hook voice announce (OHVA)
and does not have a microphone. A maximum of four 64 button modules can be
assigned to any keyset.
