Getting on-line, Adsl router quick set-up guide – Dynalink ADSL Router/ RTA770 User Manual

Page 6

Windows 98/ME:

1. From

Control Panel, double click

Network. Scroll down to highlight
TCP/IP -> (your network card). Click
Properties.

2. Select the

IP Address tab. Specify

192.168.1.x (x is a number you pick
between

2 and 254). This is the IP

address you assign to the computer.
Subnet Mask is 255.255.255.0.

3. Select Gateway tab. Enter the

router’s IP address

192.168.1.1.

Click Add. If your ISP specifies DNS
server addresses, go to the tab

DNS

Configuration. Enter the specified
addresses according to the ISP’s
instructions.

4. Click

OK & then OK to finish. The

system may ask to read the
Windows CD, and then ask to restart the computer.

You have now finished with configuring your computer.
Go to Section 5 – Getting On-line.

Getting On-line

It takes only 2 easy steps.

STEP1

GO TO THE ‘CONNECT TO INTERNET’ PAGE

Start your web browser. Enter the default
address

http://192.168.1.1. Type admin

for both User name and Password.

See Q1 in Section 10 - Troubleshooting
if you cannot get this screen.

Next you will be in the

Quick Start >

Connect to Internet page.

If your ISP specifies that your ADSL
service is PPPoE, you must now follow
Section 6 to change the router’s
connect mode to PPPoE. Check with
your ISP if you are unsure of the type of service you have subscribed to.

ADSL Router Quick Set-up Guide
