Oscillation(2)
1
2
8 MHz
MICOM
V
DD
-10%
V
SS
+10%
Fig 2-1
DESCRIPTION
Oscillatory Frequency drive Micom, it is made up 8MHz resonator oscillatory Freqency.
Ocillatory wave is as following Fig 2-1.
