Desa BDV34PA - Manual (Page 31)

31 105980
OWNER’S MANUAL
SPECIFICATIONS
BDV34NA BDV34PA
15,000/21,000 Btu/hr 16,000/20,000 Btu/hr
Gas Type Natural Propane/LP
Ignition Piezo Piezo
Manifold Pressure 3.5" w.c. 10.0" w.c.
Minimum Inlet Supply Pressure 4.5" w.c. 11.0" w.c.
Dimension, Inches/mm (HxWxD)
Fireplace (Actual size of
firebox. Measurements do not 32
3 /
16
" x 34 3 /
8
" x 18 1 /
2
" 32 3 /
16
" x 34 3 /
8
" x 18 1 /
2
"
include nailing flanges or 817 x 873 x 470mm 817 x 873 x 470mm
stand-offs.)
Carton 37" x 40" x 21" 37" x 40" x 21"
940 x 1016 x 533mm 940 x 1016 x 533mm
Weight, lbs/kg
Fireplace 123 lbs/56 kg 123 lbs/56 kg
Shipping 126 lbs/57 kg 126 lbs/57 kg
