9
THERMOSTAT
The thermostat on the refrigerator controls both the gas
and electric operation, thereby eliminating the necessity
of resetting each time a different energy source is em-
ployed.
After the initial start-up, the thermostat should be moved
from “COLDEST” to the desired temperature setting,
usually at mid setting.
TO SHUT OFF THE REFRIGERATOR
The refrigerator may be shut off while in any mode of
operation by pressing the main power ON/OFF button to
the UP (OFF) position. This shuts off all DC power to the
refrigerator, including the interior light.
START UP INSTRUCTIONS
A. A continuous 12 volt DC supply must be available for
the electronic control to function.
B. Press the main power ON/OFF button (1) to the
DOWN position.
C. Press the TEMPERATURE SELECTOR button (3)
until the lamp at the desired setting is illuminated.
AUTO MODE
1. Press the AUTO/GAS mode selector button (2) to
turn ON the Auto lamp (A). If 120 volts AC is
available, the AC mode indicator lamp (B) will
illuminate indicating AC operation. If 120 volts AC is
not available, the GAS mode indicator lamp (C) will
illuminate and the control system will automatically
switch to GAS operation.
2. If the CHECK indicator lamp (D) illuminates and the
GAS mode indicator lamp (C) is off, the controls
have failed to ignite the burner in the GAS mode.
GAS operation may be reset by pressing the main
power ON/OFF button (1) to the OFF then ON
position. (See step 2 under GAS MODE).
3. Press the TEMPERATURE SELECTOR button (3)
until the lamp at the desired position is illuminated.
GAS MODE
1. Press the AUTO/GAS mode selector button (2) to
turn OFF the Auto lamp (A). The GAS mode
indicator lamp (C) will illuminate. Within 45 seconds
the burner should be ignited and operating nor-
mally.
2. On the initial refrigerator start-up it may take longer
than 45 seconds to allow air to be purged from the
gas line. If the gas does not ignite within 45 sec-
onds the CHECK indicator lamp (D) will illuminate
and the GAS mode indicator lamp (C) will go off. To
reset when the CHECK indicator lamp (D) is
illuminated, press the main power ON/OFF button
(1) to the OFF and then ON position.
NOTE: Do not continue to reset GAS operation if
the CHECK indicator lamp continues to be illumi-
nated after several tries.
3. Press the TEMPERATURE SELECTOR button (3)
until the lamp at the desired position is illuminated.
DISPLAY PANEL
D
B C
A
ON
OFF AC GAS
AUTO
CHECK
COLD 1 2 3 4 5 COLDEST
3
E
2 1
