Dukane Data Video Projector 8105B User Manual
Page 24
1
Screen size
(diagonal)
Projection distance
Screen height
b1
b2
c1
c2
type(inch)
m
m
inch
m
inch
m
inch
m
inch
60
1.5 0.096
3.8
0.403
15.9
0.281
11.1
1.196
47.1
70
1.8 0.161
6.3
0.467
18.4
0.317
12.5
1.384
54.5
80
2.0 0.225
8.9
0.531
20.9
0.352
13.9
1.571
61.9
90
2.3 0.289
11.4
0.596
23.4
0.387
15.2
1.759
69.2
100
2.5 0.353
13.9
0.660
26.0
0.423
16.6
1.947
76.6
a
•
On a horizontal surface
•
Mounted on the wall or ceiling
F-1
F-2
T-1
Screen size
(diagonal)
Projection distance
Screen height
b1
b2
c1
c2
type(inch)
m
m
inch
m
inch
m
inch
m
inch
60
1.5 0.120
4.7
0.426
16.8
0.295
11.6
1.102
43.4
70
1.8 0.188
7.4
0.494
19.5
0.332
13.1
1.274
50.2
80
2.0 0.256
10.1
0.562
22.1
0.369
14.5
1.446
56.9
90
2.3 0.324
12.8
0.631
24.8
0.407
16.0
1.618
63.7
100
2.5 0.392
15.4
0.699
27.5
0.444
17.5
1.791
70.5
T-2
8105B, 8106B
8104WB
a
(1024 x 768) (±8%)
(1280 x 800) (±8%)
a
c2
c1
b1
b2
a
c2
c1
b1
b2
Note: Dukane models described in this document are manufactured by Hitachi and use
the same firmware and software programs. The equivalent Dukane to Hitachi models are
8104WB (CP-AW252WN),
