ITEM NOS. 20U5&2017
PARTS IV THIS PACKAi;E
A« Base
(1 pck.)
B. Washer
(4 pe*.)
C. Base MDFSbcIf
(1 pc».)
D. Rods
{12 pc».)
E. Adjustable .MOF Shelves
(9 pc».)
P. Steel plate
(2 pcs.)
C. Clips
(24 pci.)
II. Spheres wfcouplers
(4 pcs.)
M. coupler*aitachcd to rods
(8 pc»)
JNSTRUmONS
1.
Aiiach a rod lo neb coupler oo the
bm,
tigbecn Ibe rods.
2.
Inhere base shelf fnakin^ sure the
Shelf ts level.
3.
Slide a dip **G"
od
each rod by u)ueeziDe
the end.« of Che clip releaxln^ them at the
desired level.
4.
Slide shelf adjust clips so the shelves
are level
5.
Repeat 3^4 for the second shelf.
6.
Install flat metal sbclf*F** at each rod joint
then place a **£** on top of It.
7.
Attach additional rods to each coupler to
make section 2.
9. Repeat 3» 4,5»d
7 to complete the units.
9.
Before placing the last ^E** shelf, place a
washer on the rod.
10. Secure each rad siilh spheres and tlfihlea
For additional shelves write to: ATLANTICINC
P.O.Box 2399 Sjota Ke Spring. Ca 90670 USA
