ASSEMBLY INSTRUCTION FOR

1322-1

m“i_nmric*

MULTI-MEDIA STORAGE

MODELS 3010-4010

L — STEP 1:

ATTACH ROD TO '*F*.

Parts List:

-UJJJ-

4 RODS

10 DIVIDERS

THE WIDTH OFTHE DIVIDER

U CAN BE SHORTENED

AND PUCED TO ANY

POSITION

40 SHELF STOPPERS

tl_____

_____

S SHELVES

(

)—►

STEP 2:

PEACE A STOPPER, ON ALL

ASSEMBLED RODS, AT tTiE DESIRED

HEIGHT. ALL 4 STOPPERS, MUST BE

AT THE SAME LEVEL.

STEPS:

FOLLOW STEP 2 FOR THE OTHER SHEL\TES

(SHELVES 2,3,4 AND 5).

STEP 4:

TO SECURE THE STORAGE UNIT TO THE

WALL, USE THE STRAP PROVIDED AND

SCREW TO THE WALL.

nXLnnXKZ

@ 2000Atlantlc, Inc. P.O.Box 2399SpTtaFe Springs, CA90670 USA. U,S. and otherforeign patents pending

All rights reservBd-.Website: www.atlantic-lnc.coni / e^ail: custQmer_5en/[email protected]
