WARNING: Use of this tool can generate and/or disburse
dust, which may cause serious and permanent respiratory or
other injury. Always use NIOSH/OSHA approved respiratory
protection appropriate for the dust exposure. Direct particles
away from face and body.
• The label on your tool may include the following symbols. The
symbols and their definitions are as follows:
V ..............volts A ...........amperes
Hz ............hertz W ..........watts
min ...........minutes ........alternating current
.........direct current ........alternating or
.............Class I Construction ............. direct current
................. (grounded) no .........no load speed
.............Class II Construction ..........earthing terminal
................. (double insulated) .........safety alert symbol
…/min .....per minute BPM .....beats per minute
RPM .........revolutions per minute
DESCRIPTION (FIG. 1)
WARNING: Never modify the power tool or any part of it. Damage
or personal injury could result.
A. Variable speed trigger switch
B. Lock-on button
C. Forward/reverse button
D. Chuck
E. Cord protector with key holder
F. Cord set
G. Main handle
A
B
D
E
DWD010
F
G
DWD014
A
B
D
E
F
G
FIG. 1
C
SHOWN IN
FORWARD
POSITION
A
C
A
