Plumbing Parts Table
Item
Part No.
Description
Qty.
1
24309
3.0 Dia.
X
20.75 Cyl. Assy. Bucket
2
2
24314
3.0 Dia.
X
30.00 Cyl. Assy. Lift
2
3
811572
3/8
X
15" Hose 3/4 MORB x 3/4 SWFJIC
2
4
811471
3/8
X
20" Hose 3/4 MORB x 3/4 SWFJIC
2
5
811466
3/8
X
24" Hose 3/4 MORB x 3/4 SWFJIC
2
6
812947
3/8
X
22" Hose 3/4 SWFJIC x 3/4 SWFJIC
2
7
112833
Tubing - Lift Cyl. Bottom Raise
1
8
112834
Tubing - Lift Cyl. Top Drop
1
9
112937
Tubing - Lift Cyl. Common (31.0")
2
10
112835
Tubing - Bucket Cyl. Bottom Rollbk
1
11
112836
Tubing - Bucket Cyl. Top Dump
1
12
112837
Tubing - Bucket Cyl. Cross Tube
2
13
812128
Elbow 90 3/4 MJIC
X
3/4 MJIC
4
14
811414
Elbow 90 3/4 MORB x 3/4 MJIC
2
15
812069
Tee 3/4 MJIC
4
16
11362
Clip Pipe Std.
9
17
81592
Nut Hex 0.375nc gr2 pi
4
18
81344
Nut Lock (Nylon) 0.375nc grB pi
5
