795, S795, 795 HSL, S795 HSL
Main Frame Parts Table
Item
Part No.
Description
795
795HSL
S795
S795 HSL
1
31596
795 Main Frame Weldment
1
-
_
1
31595
795 HSL Main Frame Weldment
-
1
-
-
1
31597
S795 Main Frame Weldment
-
-
1
1
31600
S795 HSL Main Frame Weldment
-
-
-
1
2
24296
Quick Attach Weldment Left
1
1
1
1
3
24297
Quick Attach Weldment Right
1
1
1
1
4
112798
Tube Cross Qtach
1
1
1
1
5
108827
Pin Weldment
2
2
2
2
6
111231
Stand Weldment
2
2
2
2
7
111232
Strap Stand
2
2
2
2
8
24329
Wrench Mounting
1
1
1
1
9
110907
Pin 0.625 Dia. Stand
2
2
2
2
10
12779
Hair Pin Clip #9 Western Wire
5
5
5
5
11
111441
Levelling Rod
1
1
1
1
12
112954
Pin 1.25 Dia.
X
6.75 Long
4
6
6
6
13
112955
Pin 1.25 Dia.
X
5.00 Long
4
6
6
6
14
112800
Pin Qtach
4
4
4
4
15
113766
Bushing 1.25 ID x 1.50 OD x 1.375 Long
8
8
8
8
16
24242
Tube Cover
1
1
1
1
17
24309
3.0 Dia.
X
20.75 Bucket Cylinder
2
2
2
2
18
24314
3.0 Dia.
X
30.00 Lift Cylinder
2
2
2
2
19
24319
3.5 Dia.
X
12.00 Leveling Cylinder
-
2
-
2
20
81581
Bolt Hex 0.375nc x 2.50 gr5 pi
16
20
16
20
21
81669
Bolt Hex 0.625nc x 3.50 gr5 pi
4
4
4
4
22
81592
Nut Hex 0.375nc gr2 pi
4
4
4
4
23
81344
Nut Lock (nylon) 0.375nc grB pi
20
24
20
24
24
81967
Nut Lock (nylon) 0.625nc grB pi
6
6
6
6
25
81570
Washer Flat Std. 0.375 hs pi
4
4
4
4
26
23842
*Decal - Hyd. Self Level x 0.75
-
2
-
2
27
813356
*Decal - Buhler Allied x 1.75
2
2
2
2
28
52281-000
•Bright Orange Scotchcal #72368
12fl
12ft
12ft
12ft
29’
113488
•Decal - Quick Attach Instruction
2
2
2
2
*Part of decal replacement kit X 1256
